smartCHEM-D 1m bundle

The smartCHEM-D is a high performance, research grade Dissolved Oxygen meter. Salinity levels affect the solubility of Oxygen, so the smartCHEM-D also contains a full function Conductivity meter.

Datalogging

The smartCHEM-D comes with a 1489 reading memory. Readings can be recorded manually, or automatically logged at preset intervals.

RS232 Serial Port Interface

The capabilities of the smartCHEM-D have been expanded with the RS232 port, which is standard equipment (cable sold separately). All readings stored in memory can be downloaded to an RS232 printer or PC. The RS232 port also allows the smartCHEM-D to log directly to the printer or PC. WinTPS Communication software for Windows 3. 1 or 95, 98 ME is available.

Automatic Stability Function (ASF)

ASF adds an extra level of versatility to the smartCHEM-D. When ASF is activated, the smartCHEM-D monitors all parameters that are currently in use. When ALL parameters become stable, the readings are frozen on the display. ASF is automatically activated with extra fine settings during calibration, to ensure the most accurate possible results for the user.

ASF can also be used during Manual and Automatic Datalogging. When used during Automatic Datalogging, the smartCHEM-D will log until a stable end-point is reached for all parameters, then stop logging.

Good Laboratory Practices

To comply with GLP guidelines, the date, time and results of the last calibration are stored in memory, along with the instrument’s serial number. This data can be displayed or sent to the RS232 port. All readings stored in memory are stamped with the date and time. Warning of failed calibration is provided.

A calibration alarm can be programmed to whichever parameters the user chooses. The alarm can be set for Daily, Weekly, 2 Weekly or 4 Weekly. The calibration alarm can also be switched off.

PIN Code Access

The Access Code is system is provided for those users who need to ensure the integrity of recorded data, calibration settings and so forth. The Access Code function will prevent anyone who does not know the code from entering the menu system. Keys that are available during normal measurement, (Store, Print, Autolog and F1 to F5 ) are still available without the Access Code. This means that others are still able to carry out day-to-day work.

Easy to use

The smartCHEM-D has a 240 x 64 dot graphic display. It features a user-friendly menu system, making the manual virtually unnecessary. Full-text help and error messages are provided. All readings and messages are provided in large, bold characters.

Automatic Calibration

For Dissolved Oxygen calibration, the smartCHEM-D automatically detects whether the sensor is in a Zero DO2 solution or in air and calibrates itself accordingly. A ppM value can also be typed in in ppM mode, if the operator wishes to calibrate against a Winkler titration.

For Conductivity and TDS calibration, the user is able to define the standards to be used for calibration.

Dissolved Oxygen Stirrer Output

A 4. 5V DC output is provided for use with the YSI Self-Stirring BOD electrode. The output can be activated as required by the user , or automatically during Automatic Datalogging.

Reliability and Service

The smartCHEM-LAB is fully waterproof to IP65, so it is suitable for even the harshest laboratory or factory environments. TPS has been manufacturing top quality, reliable instruments and electrodes since 1968. The TPS Quality System has been certified in accordance with the AS/NZS ISO 9001 standard. Our service is also of the highest standard. Spares and accessories are always held in stock, and our modern service facilities ensure a rapid turn-around for maintenance and repair work.

Dissolved Oxygen

Ranges

ED1 :

0. 00 to 20. 00 ppM

20. 0 to 40. 0 ppM

0. 0 to 250. 0 % Sat'n

250 to 450 % Sat'n

0. 0 to 50. 0 % Gaseous

50 to 100 % Gaseous

YSI :

0. 00 to 25. 00 ppM

25. 0 to 40. 0 ppM

0. 0 to 300. 0 % Sat'n

300 to 450 % Sat'n

0. 0 to 60. 0 % Gaseous

60 to 100 % Gaseous

Resolution :

0. 01 1 ppM

0. 1 1 % Saturation

0. 1 1 % Gaseous

Accuracy :

+/-0. 2 % of full scale of selected ppM range

+/-0. 3 % Saturation

+/-0. 1 % Gaseous

Conductivity

TDS

Note

Dissolved Oxygen, Conductivity, and TDS ranges are automatically selected. Exact auto-range points are subject to sensor performance.

Specific Ions

Ranges : Auto-ranging in units of ppM, ppK, % and Exponential Notation

Resolution : User selectable for 3 significant digits, 2 significant digits or Auto-rounding

Accuracy : +/-Least significant digit

pH

Ranges :

0. 000 to 14. 000 pH

0. 00 to 14. 00 pH

Resolution :

0. 001 pH

0. 01 pH

Accuracy :

+/-0. 002 pH

+/-0. 01 pH

Millivolts Relative Millivolts

Range : 0 to +/-400. 0 and 0 to +/-1500 mV (auto-ranging)

Resolution :

0. 1 mV

1 mV

Accuracy :

+/-0. 15 mV

+/-1 mV.

Temperature

Range : -10. 0 to 120. 0 OC (sensor limit 45 OC)

Resolution : 0. 1 OC

Accuracy : +/-0. 2 OC

Temperature Compensation

0 to 100 OC, automatic or manual.

Calibration

Automatic calibration for all parameters. User can define standards where applicable.

Memory

1489 readings including date and time.

Automatic Datalogging

User-set for one reading every 2 to 90 seconds, minutes or hours.

RS232 Serial Port Output

1200, 9600, 19200 and 38400 Baud.

8 Bits, No Parity, 1 Stop Bit, XON/XOFF Protocol

Recorder Output (optional)

Max 0 to 2000mV output for any one parameter at one time.

Output impedance approx 1000 Ohms.

Resolution approx 2 mV.

Clock

24 Hour Calendar clock.

Displays date, month, year, hours, minutes, seconds.

Good Laboratory Practices

Date, time and value of last successful calibration for each parameter are stored. This information can be recalled or sent to the RS232 port at any time.

Calibration Alarm

Calibration Alarm can be activated for parameter of user's choice. Calibration Alarm can be set to Daily, Weekly, 2 Weekly or 4 Weekly.

Display

240 x 64 dot graphic LCD with large, bold digits, user-friendly menu system and full-text help and error messages.

Enclosure

Tough, high impact ABS. Splash resistant one-piece lid.

Dimensions

240 x 180 x 105 mm

Mass

Instrument only : Approx 1. 0 kg

Full Kit : Approx 5. 0 kg

Environment

Temperature : 5 to 45°C

Humidity : 0 to 90% R. H.

Power

12V DC via AC/DC adaptor.

AC/DC adaptor to suit specified country is supplied.
