easyFLOW-VS Peristaltic Pump

The easyFLOW-VS is an economical peristaltic pump for laboratory and low volume process control applications.

Pump rate for the standard unit is 5 L/Hr at full speed. With the small squeeze tube fitted, full speed is 1. 6 L/Hr.

Variable Speed
The easyFLOW-VS is a variable speed pump. The speed can be varied either by using the Dose Rate control manually or via External Control. External variable speed control can be either 4 to 20 mA or 0 to 1 V DC.

External On / Off Control
In addition to external variable speed control, the easyFLOW-VS can also be switched on and off externally.

Waterproof Construction
At TPS we realise that dosing pumps are sometimes used outdoors or in wet areas. The easyFLOW-VS is fully waterproof to IP65.

Australian Quality
The easyFLOW-VS is proudly designed and manufactured in Australia. Our aim is to provide you with the best quality, service and value for money. The TPS Quality System has been certified in accordance with the AS/NZS ISO 9001 standard. Since 1968, TPS has built a reputation for excellent backup service that is second to none.

Pump Rate at Full Speed
Large Tube : 5 L/Hr (standard)
Small Tube : 1. 6 L/Hr

Squeeze Tubing
Chemical resistant Santoprene tubing

Power
24V, 500mA AC/DC Adaptor to suit country of destination is supplied.
Actual power consumption approx 200mA.

Dimensions
200 x 120 x 75 mm

Mass
Pump only : Approx 500g
Full Kit : Approx 1. 0kg

Environment
Temperature : 0 to 45°C
Humidity : 0 to 90% R. H.
